Omni-λ-180D Double Monochromator/Spectrometer

Features
●   Dispersion subtraction double monochromator/spectrometer
^●Stray Light is less than 10^-9
●   Pre-aligned, pre-calibrated, designed as modular convenient for transportation and installation
●   USB2.0 interface
●   Dual gratings cover from UV-VIS-NIR spectral range
●   Wide range of accessories : filter wheel etc.

●Application

Tunable Light Source
Raman spectrum measurement
Dtector spectral responsibility measurement

Besides, we also supply 300mm/500mm double monochromator , please contact us if you have more requirement .

Model Sheet (@1200g/mm grating)

Focal Length(mm)	180
Grating size (mm)	40x40
Relative aperture	f/3.9
Resolution (nm)	0.25
Reciprocal Dispersion(nm/mm)	3.7
Wavelength Accuracy(nm)	±0.2
Wavelength Repeatability (nm)	±0.1
Stray Light	<1x10^-9
