Model:PSAXXX-11AS-X
Servo Motor ,Precision Linear Stages

PSAXXX-11AS-X adopt panasonic 100W or 200W AC servo motor and high level coupler,achieve high resolution,high speed,low vibrate;material is alluminum alloy by special craft;

Characteristic
◆ground ball screw ,achieve high postion accuracy
◆import guide ensure straightness and parallel inconjunction with our special craft
◆strict assemble craft and test method, ensure high performance
◆servo-motor and limited swithes design, convenient for choosing controller
◆limited switches ensure safety
◆different size and travels,make products abount
◆hand-wheel achieve hand adjustment

Grating Diagram

Related Products
	MC6003P Controller

Model	PSA050-11AS-X	PSA100-11AS-X	PSA150-11AS-X	PSA200-11AS-X	PSA300-11AS-X	PSA400-11AS-X
Price(USD)	1333	1500	1583	1617	1983	2150
Travel Range(mm)	50	100	150	200	300	400
Screw Pitch(mm)	4					5
Resolution (μm)	0.4					0.5
Max Speed (mm/sec)	200					250
Repeatability(μm)	<3
Backlash(μm)	<5
Straightness	<10(μm)	<10(μm)/100mm
Parallism	<15(μm)	<15(μm)/100mm
Servo Motor Power (W)	100				200
Load Capacity(Kg)	20				30
